We design, fabricate and install drive-in pallet racks across Singapore — high-density systems where the forklift drives into the storage lane itself to place and retrieve pallets. It's the go-to layout when you need maximum cube utilisation for homogeneous SKUs, and you're willing to trade selectivity for density. We've been cold-roll forming uprights, beam rails and guide rails in our Singapore workshop since 2014, and we've sized, tested and installed drive-in configurations for food distributors, 3PL hubs, pharmaceutical cold stores, and furniture warehouses from Tuas to Loyang. Every upright frame is PSB-tested; every install is matched to the actual pallet load case, forklift mast height, slab capacity, and aisle width your operation runs on.

What Is Drive-In Racking and When Should You Use It?

Drive-in racking eliminates the aisle between rows. Instead of storing one pallet deep per picking face, you stack pallets three, four, five or more deep along a single drive lane. The forklift enters the lane, places the pallet onto cantilevered rail arms, reverses out, and repeats. Because there are no internal aisles, you can often double or triple your pallet positions in the same footprint compared to selective racking.

We specify drive-in when our client ticks three boxes:

• High SKU volume, low SKU variety. You're storing the same product in quantity — beverages, dry goods, raw materials, seasonal stock.
• Last-in, first-out inventory flow is acceptable. The last pallet loaded is the first one retrieved. FIFO is difficult unless you configure the rack as drive-through (entry and exit at opposite ends), which we can do but requires twice the aisle commitment.
• Forklift operators are trained and the floor slab can handle concentrated wheel loads. Drive-in demands higher operator skill and punishes a weak slab fast.

If selectivity matters — if you need to pick any pallet at any time — we'll usually recommend selective or narrow-aisle instead. Drive-in is a specialist tool, and we only recommend it when the fit is real.

How We Fabricate Drive-In Frames and Rail Arms in Singapore

We cold-roll form our own drive-in upright profiles and rail beams on-site in Singapore. The uprights use a heavier-gauge cold-formed section than selective pallet racks because they carry both vertical load and lateral impact from forklift entry. We punch the upright face at standard 75 mm pitch to accept the rail arms, which are welded with end connectors that hook into the upright slots and lock with a safety pin.

Each rail beam is cantilevered — it projects into the lane without front-to-back cross-bracing — so deflection under load is the design constraint, not just shear. We calculate deflection per pallet load case (typically 800 kg to 1,500 kg per pallet for our clients, though we've gone higher), and we select beam profile depth and wall thickness to keep sag within 1/200 of span under full load. Every profile batch is third-party tested to PSB standards; mill certificates are available on request.

For guide rails — the vertical rails mounted to the floor that guide the forklift mast into the lane — we use 6 mm or 8 mm steel angle or channel, hot-dip galvanised or powder-coated, fixed to the slab with chemical anchors or expansion bolts depending on slab thickness and condition. Guide rails take a beating, so we oversize them and inspect anchor pull-out capacity on every install.

Site Survey, Load Calculation and Layout Planning

We don't quote drive-in from a phone call. We visit the site, measure the clear height under obstructions (sprinkler pipes, cable trays, HVAC ducts), map column positions, check the floor slab (we look for cracking, spalling, joint spacing, and surface level; ideally we want the original structural drawing or a core test if the slab is suspect), photograph the forklift fleet (mast type, lift height, fork length, turning radius), and confirm the actual pallet size and load.

From there we draw the layout in AutoCAD. Key dimensions we lock in:

• Lane depth: how many pallets deep (typically 3 to 6 for our Singapore installs; beyond 6, retrieval time and impact risk climb steeply).
• Lane width: pallet width plus 200 mm to 300 mm total clearance (100 mm to 150 mm per side). Tight tolerance saves space but demands better operators.
• Rail level spacing: pallet height plus 75 mm to 100 mm clearance, verified against forklift mast collapsed height and lift-over-load guard.
• Entry height: lowest rail level must clear the pallet load plus fork thickness plus at least 100 mm, and the forklift must be able to tilt back safely before reversing.
• Aisle width: forklift wheelbase turning radius plus 300 mm minimum; we measure this with the actual truck if possible.

We also calculate upright vertical load (sum of all pallet weights in the bay plus a 1.4 safety factor) and compare it to slab capacity. If the slab can't take it, we'll spec a steel base plate or a reinforced footing pad — extra cost, but cheaper than a slab failure six months in.

Installation, Safety and Operator Training Coordination

Our installation crew fixes the base plates to the slab, erects the upright frames with rear bracing, levels and plumbs each frame with laser, then slots in the rail arms level by level. We torque every anchor bolt to spec and pin every rail connector. Once the frame is up, we install guide rails, end-of-aisle column protectors (we use 6 mm steel tube filled with concrete or high-density polyethylene guards depending on budget), and floor marking (yellow hatching for the drive lane, red for no-go zones).

We don't train forklift operators — that's the client's or their training vendor's scope — but we do provide a one-page operating placard for each drive-in block: max pallet weight, max stack height, entry speed limit, and our contact number. We've seen enough impact damage to know that operator discipline is half the system's lifespan.

For every install above a certain height or load threshold (this varies by site use and BCA interpretation), we coordinate PE endorsement and submit structural calculations to BCA if required. We handle the paperwork; the client just needs to provide site access and the approved building plan if available.

Maintenance, Inspection and Upright Damage Repair

Drive-in racks take more abuse than selective because every pallet movement involves the forklift entering a confined lane. We recommend a visual inspection every quarter: check upright verticality with a plumb bob or laser, look for bent rail arms, inspect welds at the upright base, and verify that anchor bolts haven't loosened.

If an upright is bent beyond 5 mm out of plumb over its height, we replace it. We don't straighten uprights — the cold-formed section loses its structural integrity once buckled, and we won't re-certify it. Replacement is faster and safer. We keep common profiles in stock and can usually swap an upright within a few hours if the client can clear the affected bay.

We also offer an annual PE inspection service for clients who need it for insurance or corporate policy. The PE checks load ratings, upright condition, and slab integrity, and issues a written report. It's not legally required for most commercial warehouses, but it's cheap insurance if you're running high-value or high-risk inventory.

Drive-In vs Drive-Through vs Selective: What We Actually Recommend

Clients often ask us to compare systems. Here's how we frame it:

• Selective racking: one pallet deep, full SKU access, lower density. We recommend this when you have diverse SKUs or need FIFO. It's the default.
• Drive-in racking: multiple pallets deep, LIFO flow, highest density. We recommend this when you have a few SKUs in large quantity and LIFO is tolerable. It's a specialist layout.
• Drive-through racking: same as drive-in but open at both ends for FIFO flow. We specify this when FIFO is mandatory but you still want depth. It costs more aisle space (you need access lanes front and back) so density falls between drive-in and selective.
• Double-deep selective: two pallets deep with a double-deep reach truck. Middle ground between selective and drive-in. We recommend this when you want better density than selective but can't commit to full drive-in depth or don't want to retrain every operator.

There's no one-size-fits-all. We've installed all four types in the same warehouse for different product categories. The right system is the one matched to your actual SKU velocity, forklift fleet, and operational discipline.

Common Mistakes We've Fixed on Drive-In Installs

We've replaced or remediated dozens of drive-in systems installed by others. The recurring issues:

• Undersized rail beams. The beams were rated for the pallet weight but not calculated for deflection. After six months the rails sag visibly, pallets tilt, and forklifts scrape the underside when retrieving. We replace the beams with deeper profiles.
• Lane width too tight. The layout was drawn at exactly pallet width with zero allowance. Every entry risks an upright strike. We can't widen the lane without re-fabricating the entire frame, so the client either lives with it, retrains operators, or replaces the system.
• No guide rails or guide rails too light. The forklift has no physical guide entering the lane, or the guide is 3 mm flat bar that bends on first contact. We retrofit proper 8 mm guide channel and anchor it correctly.
• Ignoring slab capacity. The rack was sold by catalogue, no one checked the slab, and after a year the slab cracks or subsides under the upright base plates. We core-test the slab, add reinforced pads or footings, and sometimes have to relocate the entire bay.
• Wrong forklift type. Client bought a standard counterbalance when the lane depth and aisle width demand a reach truck or narrow-aisle truck. The rack is fine; the forklift can't navigate it. We re-draw the layout or the client changes trucks.

Every one of these is avoidable with a proper site survey and honest load calculation up front. That's why we insist on the slow work first.

Costing, Lead Time and What We Need from You

Drive-in racking is priced per pallet position, but the unit cost varies widely with lane depth, load rating, and height. A shallow 3-deep system at 1,000 kg per pallet and 4 m height is cheaper per position than a 6-deep system at 1,500 kg per pallet and 8 m height because the steel section and bracing requirements climb steeply.

Typical lead time from approval of shop drawing to installation complete is four to six weeks for a standard single-warehouse bay (say, 50 to 100 pallet positions). Larger projects or custom profiles run longer. We fabricate in batches, so if you're doing multiple bays or a phased rollout, the per-position cost drops.

To quote accurately, we need:

• Warehouse address and access for site visit (one to two hours on-site).
• Pallet dimensions and weight per pallet (actual, not rated truck capacity).
• SKU count and whether LIFO flow is acceptable.
• Forklift make, model, mast type, and max lift height (photos help).
• Any existing layout drawing or floor plan, even a rough sketch.

We'll visit, measure, calculate, draw the layout, and provide a fixed-price quote including fabrication, delivery, installation, PE certification (if required), and one-year warranty on materials and workmanship.

Frequently Asked Questions

Is drive-in racking suitable for a small warehouse or only large 3PL operations?

We've installed drive-in systems in warehouses as small as 2,000 square feet and as large as 80,000 square feet. Size isn't the constraint — SKU homogeneity and LIFO tolerance are. If you have three or four product lines each with 20+ pallets on hand, and you load and unload in batches, drive-in can work beautifully even in a small space. The density gain pays for itself faster in high-rent industrial estates like Jurong or Woodlands.

Can we convert existing selective racking to drive-in, or do we need to start from scratch?

Usually you need to start from scratch. Selective upright profiles aren't designed to take the lateral impact and concentrated load of drive-in operation, and the beam pitch and bracing layout are different. We've occasionally reused base plates and rear bracing if the selective system was overbuilt and still within tolerance, but the uprights, rails, and guide system are always new. If you're committed to drive-in, it's cleaner and safer to remove the old selective and install purpose-built drive-in.

How do we know if our floor slab can support drive-in racking?

We check during the site visit. We look for visible cracking, spalling at joints, and surface level, and we ask for the original structural drawing if available. If there's any doubt, we arrange a core test or pull test on the anchors. The slab needs to handle the concentrated wheel load of a fully loaded forklift plus the static load of the upright. A typical Grade 30 concrete slab at 150 mm thickness can usually handle standard drive-in with pallet loads up to 1,200 kg, but every slab is different. We calculate it, we don't assume it.

Do we need BCA or SCDF approval to install drive-in racking?

Most drive-in racking installs in standard commercial or industrial warehouses don't trigger BCA submission because the rack isn't a permanent structure and doesn't alter the building envelope. However, if the rack height approaches the building eaves, or if the warehouse is in a mixed-use or controlled area, or if the client's insurer or landlord requires PE certification, we coordinate the submission. SCDF approval is rarely required for racking alone, but if the rack layout affects fire escape routes or sprinkler head spacing, we flag it and work with the client's fire consultant. We clarify this during the site survey so there are no surprises later.

What's the typical lifespan of a drive-in racking system?

If the system is correctly sized, installed to spec, and operated with discipline, you're looking at 15 to 20 years before fatigue or corrosion becomes a concern — longer if the warehouse is climate-controlled and shorter if it's outdoor-exposed or high-humidity. The weak link is usually impact damage from forklift operators, not material failure. We've seen well-maintained drive-in systems run for two decades with only minor upright replacements. Conversely, we've seen poorly operated systems need major remediation within three years. The steel will outlast the operation if the operation respects the steel.
